Stainless Steel Decorative Plate Classification
Time:2023-02-22 Source: Hits:207

Classification by process

A. Electroplating

The process of using electrolysis to attach a metal film to the surface of metal or other material parts. It can prevent corrosion, and improve wear resistance, electrical conductivity, reflectivity, and aesthetics.

B. Water plating

In the aqueous solution, it does not rely on external power supply, and only relies on the reducing agent in the plating solution to carry out chemical reduction reaction, so that the metal ions are continuously reduced on the self-catalyzed surface to form a metal coating.

C. Fluorocarbon paint

It refers to the coating with fluorine resin as the main film-forming substance; also known as fluorocarbon paint, fluorine coating, or fluorine resin coating.

D. Spray Paint

Different colors are formed by spraying paint into the mist on a stainless steel plate with compressed air.




Classification by surface

Mirror plate (8K), brushed plate (HL,NO.4), and Wade-grain plate, etched plate, embossed plate, composite plate (combination plate)

1、Colored stainless steel mirror plate

8K plate, also known as mirror plate, polished with an abrasive solution through polishing equipment on the surface of the stainless steel plate, so that the plate surface luminosity is as clear as a mirror, and then electroplated with color.

2、Colored stainless steel brushed plate

Brushed plate (HL), also called wire drawing plate or hairline, because the grain is like a hair thin and straight. Its surface is like a filamentous texture, which is a processing process of stainless steel. The surface is matte, look closely at the texture of the top, but can not feel, then the general bright stainless steel is wear-resistant, and looks more upscale. There are many kinds of grain patterns, such as hairline (HL), Snowflake Brush (NO.4), messy pattern, Crosshatching, etc. All the patterns are processed by oil polishing machine according to the requirements, and then electroplated and colored.




3、Colored stainless steel sandblasted plate

Sandblasted plate with zirconium bead grain through mechanical equipment in the stainless steel plate surface processing, so that the plate surface presents a fine bead-like sand surface, forming a unique decorative effect. Then electroplated coloring.

4、Colored stainless steel combination process plate

According to the process requirements, various processes such as polishing hairline, coating, etching, sandblasting, etc. are concentrated on the same board surface for combined process processing. Then electroplating and coloring.

5、Colored stainless steel and grain plate

The sand pattern of the messy plate is made up of a circle of sand patterns from a distance, and up close is the non-specified messy pattern, which is ground by the irregular swing of the grinding head up and down, and then electroplated and colored. Whether it is and grain plate, brushed plate, etc. are one of the sanded plates, but the surface state of these plates is not the same, so the statement is not the same.

6、 Colored stainless steel etched plate

The etching plate is in the mirror plate, brushed plate, and sandblasted plate as the base plate, its surface through chemical methods, corrosion out of a variety of patterns after deep processing; various kinds of complex processes such as localized messy pattern, brushed, inlaid gold, titanium, etc. for etched plates, and finally realize the pattern of light and dark, colorful effect.




Classification by color

Black titanium, sky blue, Gold titanium , coffee, teal, fuchsia, bronze, rose gold, titanium white, emerald green, champagne gold, pink, Japanese gold, seven colors.

Classification by material

Stainless steel decorative plate material can be divided into 304 and 201, 304 material whether laser, bending, planing groove and other processing technology are excellent performance; 201 corrosion resistance than 304 is poor, but its plasticity, so inland cities can also be used.
